1. Single Disk, JBOD, RAID 0, 1, 5, 5 + Hot Spare, 6, 6 + Hot Spare, 10, 10 + Hot Spare
2. Online RAID Capacity Expansion & Online RAID Level Migration
3. Bad Block Scan & Hard Drive S.M.A.R.T.
4. Global Hot Spare Drive (4-bay NAS and above)
5. RAID Recovery
6. Bitmap Support

1. Apple Mac OS 10.7 or later
2. Linux and UNIX
3. Microsoft Windows 7, 8, and 10
4. Microsoft Windows Server 2003, 2008 R2, 2012, 2012 R2 and 2016

1. iSCSI Target
   • Multi-LUNs per Target
   • Up to 256 Targets/LUNs Combined
   • Supports LUN Mapping & Masking
   • Online LUN Capacity Expansion
   • Supports SPC-3 Persistent Reservation
   • Supports MPIO & MC/S
2. iSCSI LUN Backup, One-time Snapshot, and Restore
3. iSCSI Connection and Management by QNAP Finder (Windows)
4. Virtual Disk Drive (via iSCSI Initiator)
   • Stack Chaining Master
   • Max No. of Virtual Disk Drives: 8

1. Microsoft Internet Explorer 10+
2. Mozilla Firefox 8, 9, 10
3. Apple Safari 4, 5
4. Google Chrome

1. Supports VMware vSphere
2. Supports Citrix XenServer
3. Supports Windows Server 2008 R2 Hyper-V & Failover Clustering

1. Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish

1. Wake on LAN
2. Internal Hard Drive Standby Mode
3. Scheduled Power on/off (Max 15 Settings)
4. Automatic Power on after Power Recovery
5. USB and Network UPS Support with SNMP Management

1. Internal Hard Drive: EXT3, EXT4
2. External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+

1. Max No. of Users: 4,096
2. Max No. of User Groups: 512
3. Max No. of Network Shares: 512
4. Batch Users Creation
5. Import/Export Users
6. User Quota Management
7. Subfolder Permissions Support for CIFS/SMB, AFP, FTP and Web File Manager

1. TCP/IP (IPv4 & IPv6: Dual Stack)
2. Dual Gigabit NICs with Jumbo Frame
   • Failover
   • Multi-IP Settings
   • Port Trunking/NIC Teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
3. Service Binding based on Network Interfaces
4. Virtual LAN (VLAN)
5. DHCP Client, DHCP Server
6. Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
7. UPnP & Bonjour Discovery
8. USB Wi-Fi Adapter Support

1. Microsoft Active Directory (AD)
2. LDAP Server
3. LDAP Client
4. Domain Users Login via CIFS/SMB, AFP, FTP, and Web File Manager

1. Real-time Remote Replication (RTRR)
   • Works as Both RTRR Server & Client with Bandwidth Control
   • Real-time & Scheduled Backup
   • Encryption, Compression, File Filter, and Transfer Rate Limitation
2. Block-level Remote Replication
   • Works as Both Rsync Server & Client with Bandwidth Control
   • Encrypted Replication between QNAP NAS Servers
3. USB One Touch Backup (Import/Export)
4. Desktop Backup by QNAP NetBak Replicator for Windows
5. Apple Time Machine Support with Backup Management
6. Data Backup to Multiple External Storage Devices
7. Data Backup to Cloud Storage (Amazon S3, ElephantDrive)

1. Private Cloud Storage and Sharing
2. Free Host Name Registration (DDNS)
3. Auto Router Configuration (via UPnP)
4. MyCloudNAS Connect for Easy Connection (Windows utility)

1. IP Filter and Policy-based Automatic IP Blocking
2. Network Access Protection with Auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
3. Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication between QNAP NAS Servers (Rsync over SSH)
4. CIFS Host Access Control for Shared Folders
5. Antivirus Protection
6. FIPS 140-2 Validated AES 256-bit Volume-based Data Encryption*
7. AES 256-bit External Drive Encryption*
8. Importable SSL Certificate
9. Instant Alert via Email, SMS, and Buzzer

1. Windows Software: QNAP Finder
2. Create and Map Shared Folders
3. Create and Connect to iSCSI Target/LUN

1. AJAX-based User Interface
2. Smart Fan Control
3. Dynamic DNS (DDNS)
4. SNMP (v2 & v3)
5. Resource Monitor
6. Network Recycle Bin for File Deletion via CIFS/SMB and AFP
7. Comprehensive Logs (Events & Connection)
8. Syslog Client
9. Firmware Live Update
10. System Settings Backup and Restore
11. Restore to Factory Default

1. File Sharing across Windows, Mac, and Linux/UNIX
2. Shared Folder Aggregation (CIFS/SMB)
3. Web File Manager
   • Supports ISO Mounting
   • Direct File Viewing via Google Doc
   • Create and Send Download Links for Public File Sharing with Expiration Time and Password Protection

1. Supported File Formats:
   • Photo: BMP, JPG, JPE, PNG, TGA, GIF, and more.
   • Video: API, MP4, and more.
2. Image Slideshow with Background Music, Thumbnails, and Different Playback Modes
3. Online Photo Editing by Pixlr Editor
4. Geotagging Photos with Google Maps
5. Slideshow Sharing (from Private Albums) with Password Protection
6. Photo Publishing to Social Websites (Facebook, MySpace, Twitter, Plurk, and Blogger)
7. Photo Sharing by Email

1. FTP over SSL/TLS (Explicit)
2. Max No. of Concurrent Connections: 256
3. FXP Supported
4. Passive FTP Port Range Control
5. FTP Bandwidth & Connection Control
6. Unicode Support

1. Plays or Shares Music Collections with Web Browser
2. Automatic Classification via Media Library
3. Supported audio format: MP3, FLAC, OGG, WAV, AIF, AIFF, and more.
   * DRM encryption format is not supported.
4. Internet Radio (MP3)
5. Up to 8 Music Alarms

1. Remote Replication Server (over Rsync)
2. Real-time Remote Replication to another QNAP NAS or FTP Server
3. Apple Time Machine Support
4. Windows Client Backup Application: QNAP NetBak Replicator
5. Third Party Backup Software Support: Acronis True Image, CA BrightStor, ARCserve Backup, EMC Retrospect, Symantec Backup Exec, LaCie SilverKeeper, etc.

1. PC-less BT, FTP, HTTP Download (up to 500 Tasks)
2. BT Download
   • Supports TCP/UDP Tracker Protocol
   • Scheduled Download
   • Configurable Port Range
   • Bandwidth Control
   • UPnP NAT Port Forwarding
   • RSS Subscription and Download (Broadcatching)
   • Selectable Download Files
3. HTTP/ FTP Download
   • Configurable Saving Directory
   • Bulk Download with Wildcard Settings
   • RapidShare Download Support
4. QNAP Download Management Software: QGet
   • For Both Windows & Mac OS
   • Manage the Download Tasks of Multiple QNAP NAS Remotely over LAN or WAN

1. HTTP/HTTPS Connections
2. Supports WebDAV Connection
3. Support Virtual Host (Max: 32)
4. Importable SSL Certificate

1. Supports 4 IP Cameras (Optional Purchase) for Network Surveillance
2. Supports 1 Webcam via QPKG Add-on: QUSBCam

1. Built-in MySQL Server (v5.1.36)
2. Web-based Management via phpMyAdmin (QPKG)

1. Protection against the Latest Known Viruses, Trojans, and Other Threats
2. Free Virus Databases Update on Manual or Scheduled Basis
3. Multiple Scan Tasks (Max: 64, Concurrent: 5) with Custom Folder Selection and Scheduled
4. Scanning
5. Email Notification upon Task Completion or Virus Detection
6. Quarantines or Deletes Infected Files

1. Max No. of Printers: 3
2. Supports Internet Printing Protocol
   • Print Job Display and Management
   • IP- and Domain Name-based Privilege Control
3. Supports Apple Bonjour Printing

1. Centralized Log Monitoring and Archiving
2. Immediate E-mail Alerts
3. Supports Log Filtering

1. Expands Application Services by Easy Online Installation
2. A Wide Variety of Official and Community QPKG Add-ons

The actual available QPKGs may vary depending on the NAS platform.

• Business
  • eyeOS
  • GLPI
  • Squid Proxy Server
  • Vtiger CRM
• CMS
  • Gallery
  • Joomla!
  • WordPress
  • Xoops
• Communications
  • Asterisk
  • XMail
  • Xeams
• Download
  • MLDonkey
  • NZBGet
  • pyLoad
  • SABnzbdplus
  • Transmission
• Entertainment
  • IceStation
  • Plex Media Server
  • PS3 Media Server
  • Squeezebox Server
• Utilities
  • iStat
  • Optware IPKG
  • phpMyAdmin
  • Piwik
• Misc.
  • Java Runtime Environment
  • Mono
  • Python
  • QUSBCam
  • Tomcat

… and more.

1. Centralized Account Management and Authentication for Network Access
2. Supports 802.1x Security Authentication

1. Secure Remote Access: PPTP & OpenVPN VPN services
2. Remote Access to Other Resources on Local Network
3. Max No. of Clients: 30

1. Built-in TwonkyMedia Server
2. Real-time & Background Photo Transcoding
3. Supports UPnP Media Player Such as PlayStation 3 and Xbox 360
4. Supported format (The actual playback capabilities may vary depending on the UPnP client.)
   • Audio: MP3、FLAC、OGG、WAV、AIF、AIFF and more.
   • Photo: BMP, JPG, JPE, PNG, TGA, GIF, and more.
   • Video: API, MP4, and more.
   • Playlist: M3U, M3U8, WPL, PLS
